Round Hollow Seamless Aluminium Alloy Tube Profiles 6061 6003 7075 7005

Foshan Kaiya Aluminum Co., Ltd.

Round Hollow Seamless Aluminium Alloy Tube Profiles 6061 6003 7075 7005

Brand Name : KAIYAMEI

Model Number : KA-AT2256

Certification : ISO9001, CE, ROHS, testing report

Place of Origin : Foshan, Guangdong, China

MOQ : 3000kgs

Price : USD1.6-3.3/Kilogram, negotiable

Payment Terms : Western Union, T/T, MoneyGram, L/C

Supply Ability : 8000T/MOUTH

Delivery Time : 15-25 DAYS

Packaging Details : Protect film for each profile, shrink film / kraft paper exterior for each bundle, outer wooden cases

Material : 6061, 6063, 7075, 7005

Feature : Round, hollow, thick

Shape : Round

Temper : T5, T6

Alloy or not : Yes, customized grade

Surface treatment : Powder coating, polishing, sand blasting

Diameter : 30mm, 50mm, 120mm

Length : 1m, 3m, 5m, 6.2m

Contact Now

Aluminium Alloy Pipes Tubes Profiles 6061 6003 7075 7005 Round Hollow

Features:

1. The seamless aluminum tube has better pressure bearing than the seam aluminum tube.

2. The texture of the seamless tube is relatively uniform.

3. The chemical composition of the welded tube will be a little burnt in the weld part, so the mechanical properties are slightly worse but not very different.


Mechanical Properties of Sections under Room Temperature


Alloy

State
Tensile strength test Hardness test
Tensile strength Rm M pa Non-proportional Stretching Stress Stretching rate Pattern thickness HV HW
Rp0.2Mpa (A50mm%) mm HV HW
6063 T4 130 75 14 -
T5 160 110 8 0.8 58 8
T6 205 180 8 -

6061
T4 184 110 16 -
T6 265 245 8 -
6082
(6351)
T4 205 110 12 -
T6 290 250 6 -

Round Hollow Seamless Aluminium Alloy Tube Profiles 6061 6003 7075 7005Round Hollow Seamless Aluminium Alloy Tube Profiles 6061 6003 7075 7005Round Hollow Seamless Aluminium Alloy Tube Profiles 6061 6003 7075 7005Round Hollow Seamless Aluminium Alloy Tube Profiles 6061 6003 7075 7005

Packing : Protect film for each profile, shrink film/Kraft paper exterior for each bundle or pack as customer request.
FOB port: Foshan, Shenzhen, Guangzhou
Delivery time: 15-20 days after receiving the deposite.
Payment term: 30% deposite and 70% balance after the delivery
Brand name: Kaiyamei Aluminum
Material: 6063 Alloy
Temper: T5
Finish: Mill Finished, Anodize, Electrophoresis, Powder Coating ,Polish, Wood grain, Sand Blasting
Color: Clear Satin, Bronze, Black, Golden, Silver, Steel Gray......
Thickness: Customize
MOQ: 500KG. Usually 12 tons for a 20 feet container; 24 tons for a 40 feet container.
Length: 5.8-5.98m, or as customer's request
Sample delivery: Two weeks (one week for mould +one week making sample)
Sample design: It is better we can get your drawing or sample, we mainly make according to your design, and we can keep confidential for your design.
Maximum extruder machine: 8000 tons; Minimum extruder machine: 500 ton
If the profiles are customized, we will make the sample first, after we get the confirmation from you, we will start production.


General Chemical Composition of Alloy

Alloy 6063(%) 6061(%) 6082(%)
Silicon Si 0.20~0.60 0.40~0.80 0.7~1.2
Iron Fe 0.35 0.70 0.5
Copper Cu 0.10 0.15~0.40 0.1
Manganese Mn 0.10 0.15 0.4~0.8
Manganese Mg 0.45~0.90 0.18~1.2 0.6~0.8
Chromium Cr 0.10 0.04~0.35 0.25
Zine Zn 0.10 0.25 0.2
Titanium Ti 0.10 0.15 0.1
Others(each) 0.05 0.05 0.05
Others 0.15 0.15 0.15
Aluminum Remainder Remainder Remainder

Round Hollow Seamless Aluminium Alloy Tube Profiles 6061 6003 7075 7005Round Hollow Seamless Aluminium Alloy Tube Profiles 6061 6003 7075 7005

Round Hollow Seamless Aluminium Alloy Tube Profiles 6061 6003 7075 7005

Our advantage:

KAIYA Aluminum is specialized in aluminum profile, we are the " Top 20 Enterprise of Construction Aluminum Industry" in Foshan Guangdong China and products with ISO9000 ISO9001 ISO1400, CE standard.

1.Advanced Equipments

Our production equipments are imported from Switzerland, Germany, Japan. Our products were exported to many countries in North America, Africa, Europe and South-east Asian like America, Canada, Australia, Germany, France, Philippine, etc
2.Professional Work Team
We have professional work team who can making nice quality in short time. More than 50 modern management administrators, 28 senior technical engineers, over 800 production workers.
3.Large-scale Production Base
Our production area covers over 80000 square meters to meet large order quantity and fast delivery all the time.

Our Package

Round Hollow Seamless Aluminium Alloy Tube Profiles 6061 6003 7075 7005

1, Pearl cotton film+ shrink film

2, pearl cotton film + plastic film

3, pearl cottom film/shrink film +kraft paper

4, wood pallet

5, Any customized package is available.

We are welcome your inquiry, our team on line 24 hours!

Any inquiry or question welcome dirctly contact or via mail: yezhi@kaiya-aluminum.com
